Launched production of improved version of the ultra-high stability OCXO in 20x20 mm steal case. Owing to renewed design of the internally heated crystal resonator (IHR) and of the oscillator circuitry the new OCXO insures up to 1×10
-10
frequency stability in (-40 +80)°С range, 0.1 ppb/day and 20 ppb/year aging, to 1.5×10
-12
/1 s Allan variance. Phase-noise of the МХОDR model operating at 10 MHz: -105 dBc/Hz @ 1 Hz, -135 dBc/Hz @ 10 Hz, -160 dBc/Hz @ 1 kHz, -170 dBc/Hz @ 10 kHz. The OCXO operates at 5-100 MHz frequencies, consumes about 1.2 W and is intended for various modern applications with ultimate requirements to the frequency stability of the reference signal.
Electronica 2016
Visit us at ELECTRONICA 2016 Hall B5, Booth 112
